Cement Mill
Cement Mill
HotSpecification:φ1.83×7-φ4.6×14m
Processing capacity:6.5-135t/h
Motor power:245-4200kw
E-mail:market@hxjq.com
Send Inquiry
Introduction to Cement Grinder
The cement mill or cement grinder is the key equipment for further crushing after the materials are broken. The cement miller is widely used for cement, silicate products, new building materials, refractory materials, fertilizer, black and non-ferrous metal and glass ceramics. The cement mill is available in both wet process grinding and dry process grinding.
Technical data
| Spec./m (Dia.×Length) |
Speed(r/min) | Feeding Size(mm) | Capacity(t/h) | Griding Media Loading(t) |
Main Motor (KW) |
Main Reducer | Weight (t) |
| Ф1.83×7.0 | 23.8 | ＜20 | 3～5 | 22 | 245 | ZD60 | 43.5 |
| Ф1.83×9.5 | 24.1 | ＜20 | 5～7 | 31 | 355 | ZD70 | 56 |
| Ф2.2×9.5 | 21.5 | ＜20 | 8～10 | 41 | 475 | ZD70 | 74 |
| Ф2.2×11 | 21.5 | ＜20 | 10～12 | 50 | 570 | ZD80 | 109 |
| Ф2.4×11 | 20.3 | ＜20 | 12～14 | 57 | 630 | ZD80 | 116 |
| MBY560 | |||||||
| Ф2.4×13 | 20.3 | ＜20 | 14～16 | 68 | 800 | MBY710 | 138 |
| JDX710 | |||||||
| Ф2.6×11 | 19.7 | ＜20 | 15～16 | 69 | 800 | MBY710 | 138 |
| JDX710 | |||||||
| Ф2.6×13 | 19.7 | ＜20 | 16～18 | 82 | 1000 | MBY800 | 158 |
| JDX800 | |||||||
| Ф3.0×12 | 18.2 | ＜20 | 18～20 | 100 | 1250 | MBY800 | 182 |
| JDX800 | |||||||
| Ф3.0×13 | 18.2 | ＜20 | 21～23 | 108 | 1400 | MBY900 | 190 |
| JDX900 | |||||||
| Ф3.2×13 | 17.8 | ＜20 | 25～27 | 128 | 1600 | MBY1000 | 230 |
| JDX1000 | |||||||
| Ф3.2×14 | 17.8 | ＜20 | 28～30 | 138 | 1800 | MBY1000 | 249 |
| JDX1000 | |||||||
| Ф3.5×13 | 17.3 | ＜20 | 32～35 | 156 | 2000 | JS130-A | 275 |
